たった1ラックに157PB、キオクシアとDellが超高密度ストレージを発表
キオクシアとDellが、SSD640台を使う157 PBのラック構成を発表した。既出の2U構成からラックへの集約が進む一方、導入効果を比べるには実効容量と電力・冷却の条件が問われる。
KIOXIA(キオクシア)は、2019年に設立された日本の半導体メーカーであり、本社を東京都に置く。前身は東芝のメモリ事業部門を継承した東芝メモリであり、NAND型フラッシュメモリおよびSSD(ソリッドステートドライブ)の設計・製造を主力事業とする。東京証券取引所に上場しており、データセンター向けのエンタープライズSSDからコンシューマー向け製品まで、幅広いストレージ製品群を展開している。
KIOXIAの起源は東芝の半導体事業にさかのぼる。2017年1月に東芝メモリとして分社化され、その後2019年1月に現在の社名であるKIOXIAへと改称した。NAND型フラッシュメモリの発明者としての歴史を持つ企業であり、長年にわたり業界の技術革新を主導してきた立場にある。分社化以降も、旧東芝メモリ時代からの製造拠点や研究開発体制を引き継ぎ、国内外に生産・開発拠点を展開している。
NAND型フラッシュメモリ市場において、KIOXIAは主要サプライヤーの一社として位置づけられる。同社の製品はTLCやQLCといった多値記録技術を採用し、容量単価の低減とともに、DRAMレス設計やHMB技術によるTCO最適化を図る製品ラインナップを持つ。インターフェース面ではPCIe 5.0対応製品の投入も進めており、AIワークロードの拡大に伴うストレージ性能要求の高まりに対応する姿勢を示している。NAND型フラッシュメモリは記憶装置の基盤技術であり、半導体業界全体のサプライチェーンにおいてDRAMメーカーと並ぶ重要な位置を占める。
2026年6月には、クライアント向けSSDの新シリーズ「KIOXIA BG8」と「KIOXIA EG7」を発表した。BG8はPCIe 5.0に対応しメインストリームPC向けに高速ストレージを提供する製品であり、EG7はQLC NANDを採用してコストパフォーマンスを重視した構成となっている。両シリーズともDRAMレス設計とHMB技術を採用し、AIインフラ需要による部材価格高騰が続く市場環境の中で、TCOの最適化を狙う戦略が示された。
同じく2026年6月には、AI需要による旺盛な部品調達が続く中で、NAND型フラッシュメモリの供給が逼迫し、2026年の生産分が全量完売する状況にあることが伝えられた。かつて1TBのSSDが低価格で入手できた時代が終わりつつあることを示す事例として取り上げられ、市場構造の変化を象徴する出来事として報じられた。
こうした動きは、NVIDIAによるGPU向けストレージ直接アクセスAPI「cuFile」のオープンソース化や、PCI-SIGによるPCIe 8.0仕様策定の前倒しなど、AIインフラにおけるストレージI/Oの重要性が高まる業界全体の潮流とも連動している。NAND型フラッシュメモリおよびSSDを主力とするKIOXIAにとって、AI需要に伴う需給逼迫と技術要求の高度化は、事業機会と供給制約の両面で影響を及ぼす要因となっている。

キオクシアとDellが、SSD640台を使う157 PBのラック構成を発表した。既出の2U構成からラックへの集約が進む一方、導入効果を比べるには実効容量と電力・冷却の条件が問われる。

米国では、iPhone 18 Proの512GBから1TBへの追加料金が倍の400ドルに。各世代の256GBから1TBへの追加料金は400ドルから600ドルに上がり、1TBの本体価格は前世代より300ドル高い。

Sandiskの2027会計年度第1四半期は売上110億ドル、粗利率85.0%。売上は前年同期から87億ドル増えたが売上原価の増加は0.3億ドルにとどまった。増益の主因は価格とみる根拠と、外れる条件を決算書から検証する。

Samsung Electronicsの7〜9月期確定決算で、営業利益107.4兆ウォンの99.2%、設備投資29兆ウォンの93.8%をDS部門が占めた。利益がメモリ市況に左右される構造にあるとみる理由を、公式資料の数字から読み解く。

SK hynixの7〜9月期は売上高と営業利益が過去最高となった。長期供給契約の顧客は14社に増え、HBM4の増産と約100兆ウォンの年間還元目標を進める。

SK hynixは10月23日、子会社SolidigmのIPO検討を打ち切り、米国での追加生産設備は必要だと述べた。ただし声明は工場の建設を決めたとは書かず、投資の時期・規模・資金調達は検討を続けるとする。声明文の記述範囲から、新工場の現在地を読む。

Micronは4F² DRAMを採用せず、6F²の延伸と3D DRAM開発を進める。キャパシタピッチを重く見る判断を、SK hynixの動作実証やキオクシアの研究と照合し、密度と量産性の違いを読む。

キオクシアが企業向けSSD「CM9」に直接液冷対応モデルを追加した。PCIe 5.0を維持し、空冷でも使える。容量とDWPDから見た用途の違い、SNIA規格が定める冷却面と圧力を解説する。

NVIDIAがGPU用ストレージ直接アクセスAPI「cuFile」をオープンソース化し、GPUがCPUを介さずストレージI/Oを制御するSCADAアーキテクチャの標準化を40社超で推進。AI推論のボトルネックが計算からデータ供給に移る中、ストレージ業界の構造変化が始まる。

超党派上院議員6名がAppleに中国CXMTとYMTC製メモリの不使用を8月21日までに確約するよう求めた書簡を、2022年のYMTC撤回劇や書簡署名議員の地元投資利害と重ねて読み解く。AI逼迫とMicronの2500億ドル投資も焦点。

SK hynixの2026年4〜6月期決算は、売上高と営業利益で過去最高を更新したが、汎用DRAMの急騰や製品構成の変化により市場予想には届かなかった。HBMの価格体系や出荷時期のずれが影響したものの、高い利益率と財務余力を背景に次世代製品への投資を加速させる方針だ。

IDCの予測によれば、部材不足やAI需要に伴うメモリ価格の高騰により、2026年のPC平均販売価格は17%上昇し出荷台数も大幅に減少する見通しだ。低価格モデルの投入も期待されるが、2027年末までは構成の妥協や実質的な値上がりが続く。

PCI-SIGは、x16構成で最大1TB/sの双方向帯域幅を提供するPCIe 8.0の仕様ドラフト0.5を前倒しで公開し、2028年の最終仕様策定を目指している。この規格は、256 GT/sへの高速化に伴う信号減衰を克服するため、PAM4シグナリングやFLITエンコーディングを維持しつつ、下位互換性を保ちながら新たな物理コネクタ技術の評価を進めている。

AIインフラ特需による部品価格高騰がコンシューマーPC市場に逆風となる中、キオクシアはクライアント向けSSDの新シリーズ「KIOXIA BG8」と「KIOXIA EG7」を発表した。BG8はPCIe 5.0対応でメインストリームPCに高速ストレージをもたらし、EG7はQLC NAND採用でコストパフォーマンスを追求しつつ、両シリーズともにDRAMレス設計とHMB技術でTCOを最適化している。

TSMCはA13プロセス技術を発表したが、これはA14の後継ではなく、A14をベースにした縮小版と位置付けられている。A13はA14との完全後方互換を保ちつつ6%の面積削減を実現し、顧客の設計移行負担を抑えることを重視した派生ノードである。この発表は、A12やN2U、先進パッケージ技術と合わせて、TSMCが先端ロジックと先進パッケージの全体的な更新周期を提示していることを示している。

かつて、1TBのSSDが約1万円以下で手に入った時代は、静かに、しかし確実に幕を下ろしたようだ。 NAND型フラッシュメモリの発明者であり、業界の巨人であるキオクシア(旧東芝メモリ)から発せられた警告は、テクノロジー業界 […]

世界的な投資銀行であるMorgan Stanleyが実施した最新の台湾サプライチェーン調査は、テクノロジー業界に衝撃と安堵の両方をもたらす極めて興味深い事実を明らかにした。 2026年の市場投入が見込まれるiPhone( […]

2025年後半、世界の半導体メモリ市場で静かな、しかし大きな地殻変動が起きている。PCやスマートフォンのストレージとして不可欠な「NANDフラッシュメモリ」の価格が急騰。その背後には、Samsung Electronic […]

生成AIの爆発的な進化が、世界の産業構造を根底から揺さぶっている。その中心で今、最も激しい需給の嵐にさらされているのが、AIの頭脳を支えるメモリ半導体だ。この未曾有の需要を捉えるべく、韓国の半導体大手SK hynixが社 […]

Windows 11 24H2向け累積更新プログラム「KB5063878」が、特定のNVMe SSDをシステムから消失させる深刻な不具合を引き起こしている問題で、大手SSDコントローラメーカーPhisonは遂に沈黙を破っ […]
The growth of the information and communication technology sector has vastly accelerated in recent decades because of advancements in digitalization and Artificial Intelligence (AI). Scope 1, 2, and 3 greenhouse gas emissions data of the top six semiconductor manufacturing companies (Samsung Electronics, Taiwan Semiconductor Manufacturing Corporation, Micron, SK Hynix, Kioxia, and Intel) were gathered from the publicly accessible Carbon Disclosure Project’s (CDP) website for 2020. Scope 3 emissions had the largest share in total annual emissions with an average share of 52%, followed by Scope 2 (32%) and Scope 1 (16%). Because of the absence of a standardized methodology for Scope 3 emissions estimation, each company used different methodologies that resulted in differences in emissions values. An analysis of the CDP reporting data did not reveal information on strategies implemented by companies to reduce Scope 3 emissions. The use of renewable energy certificates had the largest effect on decarbonization centered on reducing Scope 2 emissions, followed by the deployment of perfluorocarbon reduction technologies to help reduce Scope 1 fugitive emissions. Technology-specific marginal abatement costs of CO2 were also estimated and varied between −416 and 12,215 USD/t CO2 eq., which primarily varied depending on the technology deployed.
DRAM cell scaling down to the 14 nm design rule (D/R) has already been productized by major DRAM players such as Samsung, Micron, and SK Hynix. They’re developing n+1 (12~13 nm) and n+2 (11 nm or beyond) so-called D1b (D1β), D1c (D1γ), and D1d (D1δ) or even D0a generation now, which means DRAM cell D/R might be able to further scale down to single digit nm with EUVL adoption for DRAM cell/core patterning. The cell design scaling down is getting slower due to many scaling issues including patterning, leakage, and sensing margin. Major DRAM players have applied EUVL masks (such as SS_BLP/H_SC2) on DRAM and will expand it for the next generation. Current 6F2 cell architecture with 1T+1C will be moving over to 4F2 or 3D DRAM in an 8~9 nm D/R DRAM generation due to scaling limitations, which will be D0b or D0c. Although they change to 3D DRAM with a little relaxed CDs, EUVL will be a must for the performance and yield improvement (defects) in DRAM core areas such as very dense WLD and SA patterns just near the cell array. HKMG DRAM process has been adopted on Graphic DRAM and advanced DDR5 DRAM products by Samsung and Micron, although etching and high-k engineering are different for each. Major NAND manufacturers are still in the race to increase the number of vertical 3D NAND gates, they all have already introduced their own 176L/232L/238L 3D NAND devices. Samsung V-NAND, KIOXIA/WDC BiCS, Intel FG CuA, Micron CTF CuA, SK Hynix 4D PUC, and YMTC Xtacking 3D NAND products are the mainstream for SSD and mobile storage applications. Many innovative processes and designs have been adopted, however, lots of challenges are still there to overcome. Although lithography burdens were reduced by changing 2D to 3D, instead, UHAR etching/cleaning/filling-related developments are ongoing. Micron already exited XPoint memory, and Intel is winding it down as well. For SCM applications, fast NAND and some Emerging Memory (EM) devices such as Z-NAND, XL-FLASH, and STT-MRAM will cover the market needs in the future. Due to the difficulties of the EM materials etching, they’re currently limited to embedded and low-density applications only. We’ll discuss current and future challenges on DRAM, 3D NAND, and Emerging memory including process, design, and materials.
Ion beams have many applications. Junior Associate Professor Masahi Nojima, Research Institute of Science and Technology at the Tokyo University of Science, Japan, is working to create a new generation of ion beams. Already, he has successfully developed new techniques for producing focused ion beams (FIB). In his most recent work, Nojima has developed a metallic solution ion source that will be used to construct unknown functional materials by using ion beams made up of specific elements. The metallic solution ion source can generate a copy of an original structure using elementally selected materials. With support from the Japan Society for the Promotion of Science (JSPS), KAKENHI, the academic incentive system of the KIOXIA Corporation 2021 and the Toshiba Electric Devices & Storage Corporation 2021, Nojima is seeking to open up new materials for use as ion sources utilising electrospray ionisation (ESI) methods. By harnessing the elements of FIBs primarily created from liquid metal ion source (LMIS) by field ionisation processes, Nojima hopes to create new generations of ion beams. To date, he and the team have displayed the result of mass separating metallic ion solution ion beams on random conditions and, looking ahead, intend to estimate the stopping range of mass selected ion beams in solid materials.
In semiconductor manufacturing, major issues include automation of the operation, expansion of the production scale, and cost reduction and competitiveness enhancement by means of quality control. On Kioxia's production sites, a vast amount of data is collected from automated production lines. AI technologies are being applied to the data in order to implement information systems capable of quality monitoring and problem solving, which helps us keep high product quality. In this paper, three case studies of AI technology applications are reported. The first two cases are from the production stage, one being an application to yield analysis, and another being an application to defect inspection. The last case is from the design stage, an application to the topography simulation. On the other hand, the creation of artwork is a rapidly emerging field for the AI application. TEZUKA2020, a project in which AI and human collaboratively tried to produce a new piece of manga by the legendary Japanese artist Osamu Tezuka, was recently carried out as an ad campaign to promote Kioxia's corporate name. The project is briefly reported in this paper.
